STL8DN6LF6AG Overview

SMD/SMT Mounting-Style PowerFlat-8 Si is the technology used. Number of channels: 2 Channel Configuration 2 N-Channel Transistor type: 2 N-Channel Power-off control: 55 W Maximum operating temperature of + 175 C Minimum operating temperature: - 55 C This product has a 7 ns of 16 ns. This product has a 20 ns of 16 ns. This product's +/- 20 V. The ID of continuous drain current is 32 A. This product has a Vds-Drain-Source-Breakdown-Voltageof 60 V. This product has a 1 V Vgs-th gate-source threshold voltage for efficient power management. The 31 mOhms for this product is 12 Ohms. The transistor polarity is N-Channel. 'Typical-Turn-Off-Delay-Time' of 56 ns This product has a 9.6 ns. Qg-Gate-Charge is 27 nC. This product operates in Enhancement channel mode for optimal performance.

STL8DN6LF6AG Image

STL8DN6LF6AG Specifications

• Manufacturer STMicroelectronics
• Product Category Transistors - FETs, MOSFETs - Single
• Mounting-Style SMD/SMT
• Package-Case PowerFlat-8
• Technology Si
• Number-of-Channels 2 Channel
• Configuration 2 N-Channel
• Transistor-Type 2 N-Channel
• Pd-Power-Dissipation 55 W
• Maximum-Operating-Temperature + 175 C
• Minimum-Operating-Temperature - 55 C
• Fall-Time 7 ns
• Rise-Time 20 ns
• Vgs-Gate-Source-Voltage +/- 20 V
• Id-Continuous-Drain-Current 32 A
• Vds-Drain-Source-Breakdown-Voltage 60 V
• Vgs-th-Gate-Source-Threshold-Voltage 1 V
• Rds-On-Drain-Source-Resistance 31 mOhms
• Transistor-Polarity N-Channel
• Typical-Turn-Off-Delay-Time 56 ns
• Typical-Turn-On-Delay-Time 9.6 ns
• Qg-Gate-Charge 27 nC
• Channel-Mode Enhancement
