| Mfr. #: | SN74LS136DG4 |
|---|---|
| Өндіруші: | Texas Instruments |
| Сипаттама: | XOR Gate 4-Element 2-IN Bipolar 14-Pin SOIC Tube - Rail/Tube (Alt: SN74LS136DG4) |
| Өміршеңдік кезең: | Осы өндірушіден жаңа. |
| Деректер тізімі: | SN74LS136DG4 Деректер тізімі |
Product belongs to the 74LS series. Tube Alternate Packaging is the packaging method for this product 14-SOIC (0.154", 3.90mm Width) Operational temperature range: 0°C ~ 70°C Surface Mount mounting type Voltage Supply Range: 4.75 V ~ 5.25 V Supplier device package: 14-SOIC 4 is 8. - maximum quiescent current. XOR (Exclusive OR) logic type 0.8V is a Logic-Level-Low; 2V is the Logic-Level-High
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
SN74LS136DG4 Specifications
