LM2941CS

LM2941CS Overview

Product belongs to the LM2941C series. Tube is the packaging method for this product Weight of 0.056128 oz SMD/SMT Mounting-Style TO-263-5 Operational temperature range: 0°C ~ 125°C Surface Mount mounting type Output-Type: Adjustable Supplier device package: DDPAK/TO-263-5 6 V ~ 26 V voltage input Number-of-Outputs: 1 Output Output voltage: 5 V ~ 20 V Positive Adjustable regulator topology The product has 1 of 1. Maximum operating temperature of + 125 C Minimum operating temperature: 0 C Output voltage: 5 V to 20 V Maximum Input Voltage: 26 V Output current: 1 A The product's - 15 V is 5.1 V. Load regulation is 10 mV/V. Input bias current of 10 mA This product has a 15 mA of 7 mA, making it ideal for low-power applications. Reference voltage is 1.313 V . The 0.11 V at 100 mA 0.5 V at 1 A. The maximum 0.2 V at 100 mA 0.8 V at 1 A is 360 mV. This product's 10 mV/V is 0.01 %/V.

LM2941CS Image

LM2941CS Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - Voltage Regulators - Linear
• Series LM2941C
• Packaging Tube
• Unit-Weight 0.056128 oz
• Mounting-Style SMD/SMT
• Package-Case TO-263-5
• Operating-Temperature 0°C ~ 125°C
• Mounting-Type Surface Mount
• Output-Type Adjustable
• Supplier-Device-Package DDPAK/TO-263-5
• Voltage-Input 6 V ~ 26 V
• Number-of-Outputs 1 Output
• Current-Output 1A
• Voltage-Output 5 V ~ 20 V
• Regulator-Topology Positive Adjustable
• Voltage-Dropout-Typical 0.5V @ 1A
• Number-of-Regulators 1
• Current-Limit-Min -
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature 0 C
• Output-Voltage 5 V to 20 V
• Input-Voltage-MAX 26 V
• Output-Current 1 A
• Input-Voltage-MIN - 15 V
• Load-Regulation 10 mV/V
• Ib-Input-Bias-Current 10 mA
• Quiescent-Current 15 mA
• Reference-Voltage 1.313 V
• Dropout-Voltage 0.11 V at 100 mA 0.5 V at 1 A
• Dropout-Voltage-Max 0.2 V at 100 mA 0.8 V at 1 A
• Line-Regulation 10 mV/V
