LM311M Overview

This product is manufactured by Texas Instruments. The product can operate at a maximum temperature of SMD/SMT. SOIC-8 package/case type is utilized by this product. The comparator type of this product is General Purpose for versatile use. This product is equipped with 1 Channel for efficient performance. The output type is Open Collector. This product has an 250 nA of 5 uA for precise signal processing. Supply Voltage - Max: 30 V Supply Voltage - Min: 5 V 200 ns response time The minimum operating temperature of this product is 0 C. The product can operate at a maximum temperature of + 70 C. Tube packaging for easy dispensing The height of the product is 1.45 mm. 4.9 mm long Analog Comparators Supply Type: Single, Dual This device belongs to the Voltage Comparator type. Texas Instruments is a trusted brand for quality electronics This product does not have a Shutdown feature, ensuring continuous operation. 1. The maximum dual supply voltage is +/- 15 V. +/- 2.5 V minimum dual supply voltage 9 V, 12 V, 15 V, 18 V, 24 V, 28 V operating supply voltage range 500 mW (1/2 W) Analog Comparators product type 95 of 100 Amplifier ICs as subcategory 1. 0.005044 oz of Unit Weight

LM311M Image

LM311M Specifications

• Manufacturer: Texas Instruments
• Product Category: Analog Comparators
• RoHS: N
• Mounting Style: SMD/SMT
• Package / Case: SOIC-8
• Comparator Type: General Purpose
• Number of Channels: 1 Channel
• Output Type: Open Collector
• Ib - Input Bias Current: 250 nA
• Vos - Input Offset Voltage: 7.5 mV
• Supply Voltage - Max: 30 V
• Supply Voltage - Min: 5 V
• Operating Supply Current: 7.5 mA
• Response Time: 200 ns
• Minimum Operating Temperature: 0 C
• Maximum Operating Temperature: + 70 C
• Packaging: Tube
• Features: Strobe, Vos Adj Pin
• Height: 1.45 mm
• Length: 4.9 mm
• Product: Analog Comparators
• Series: LM311-N
• Supply Type: Single, Dual
• Technology: Bipolar
• Type: Voltage Comparator
• Width: 3.9 mm
• Brand: Texas Instruments
• Shutdown: Shutdown
• Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V
• GBP - Gain Bandwidth Product: -
• Maximum Dual Supply Voltage: +/- 15 V
• Minimum Dual Supply Voltage: +/- 2.5 V
• Operating Supply Voltage: 9 V, 12 V, 15 V, 18 V, 24 V, 28 V
• Pd - Power Dissipation: 500 mW (1/2 W)
• Product Type: Analog Comparators
• Factory Pack Quantity: 95
• Subcategory: Amplifier ICs
• Vcm - Common Mode Voltage: 0.5 V
• Voltage Gain dB: 106.02 dB
• Unit Weight: 0.005044 oz
