DN1509K1-G

DN1509K1-G Overview

This product is manufactured by Microchip. The product can operate at a maximum temperature of SMD/SMT. SOT-23-5 package/case type is utilized by this product. This product is equipped with 1 Channel for efficient performance. Vds rating of 90 V 200 mA continuous drain current Rds On value of 6 Ohms Gate-Source Voltage: 3.5 V The minimum operating temperature of this product is - 55 C. The product can operate at a maximum temperature of + 150 C. 490 mW This product has a Single configuration. The Channel Mode is set to Depletion. Reel packaging for easy dispensing The height of the product is 1.45 mm. 2.9 mm long Microchip Technology is a trusted brand for quality electronics 25 ns fall time MOSFET product type Rise Time is 16 ns. 3000 of 100 MOSFETs as subcategory Turn-off delay time is 15 ns. The typical turn-on delay time is 12 ns. 1. 0.000222 oz of Unit Weight

DN1509K1-G Image

DN1509K1-G Specifications

• Manufacturer: Microchip
• Product Category: MOSFET
• RoHS: Y
• Technology: Si
• Mounting Style: SMD/SMT
• Package / Case: SOT-23-5
• Number of Channels: 1 Channel
• Transistor Polarity: N-Channel
• Vds - Drain-Source Breakdown Voltage: 90 V
• Id - Continuous Drain Current: 200 mA
• Rds On - Drain-Source Resistance: 6 Ohms
• Vgs - Gate-Source Voltage: 3.5 V
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 150 C
• Pd - Power Dissipation: 490 mW
• Configuration: Single
• Channel Mode: Depletion
• Packaging: Reel
• Height: 1.45 mm
• Length: 2.9 mm
• Width: 1.6 mm
• Brand: Microchip Technology
• Fall Time: 25 ns
• Product Type: MOSFET
• Rise Time: 16 ns
• Factory Pack Quantity: 3000
• Subcategory: MOSFETs
• Typical Turn-Off Delay Time: 15 ns
• Typical Turn-On Delay Time: 12 ns
• Unit Weight: 0.000222 oz
